SS Sight Glass Valve

Get a Price/Quote

MOQ : 100 Pieces

SS Sight Glass Valve Specification

Material
SS 304 / SS 316 Stainless Steel

Control System
Manual

Features
360 visual flow indication, corrosion resistant, easy installation, robust glass window, leak-proof design

Connection Type
Flanged, Threaded, or Welded ends

Valve Size
DN15 to DN100 (1/2 to 4)

Valve Type
Sight Glass

Sealing
PTFE or EPDM gaskets

Application
Industrial liquid observation, chemical processing, food and beverage industries, pharmaceutical operations

Structure
Flanged body with transparent viewing window

Type
Sight Glass Valve

Power
Manual

Pressure
Up to 10 bar (145 psi)

Media
Liquids, Gases

Port Size
1/2 to 4 (custom sizes available on request)

Temperature
Up to 180C (may vary by gasket type)

Disc
SS304/SS316 Stainless Steel

Glass Material
Borosilicate toughened glass

Maintenance
Easy to disassemble and clean

Inspection Window
Full view or double window (based on model)

Flow Direction
Unidirectional or bidirectional (depending on construction)

Weight
Varies with size (e.g., approx. 2 kg for DN25)

Body Finish
Mirror polished or matt finish

Gasket Options
PTFE, EPDM, Viton available

Installation Position
Horizontal or vertical orientation

Standards
Meets ASME B16.5 / DIN standards

End Connection
ANSI B16.5, DIN, or custom flange standards

SS Sight Glass Valve Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Pieces Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About SS Sight Glass Valve

Experience breathtaking clarity and performance with our SS Sight Glass Valve. Designed using robust SS 304/SS 316 stainless steel and astounding borosilicate toughened glass, this valve ensures unbeatable durability and leak-proof reliability across industries. Choose from mirror polished or matt finishes, horizontal or vertical installations, and full or double inspection windows. With easy maintenance, versatile gasket options, and a reduced price offer, you get maximum safety and effortless monitoring. Try now and purchase for unmatched value in chemical, pharmaceutical, food, and industrial liquid observation applications.

Versatile Usage and Advantages in Industrial Applications

The SS Sight Glass Valve is specifically designed for visual monitoring and inspection of liquid or gas flow in chemical processing, food and beverage manufacturing, and pharmaceutical operations. Its corrosion-resistant construction and 360 visual flow indication provide reliability in demanding environments. The valve is easy to install in both horizontal and vertical pipelines, ensuring robust performance and superior safety wherever process observation is essential. Ideal for pressure monitoring up to 10 bar and temperatures up to 180C.

Sample Policy, Payment, and Delivery Terms

We offer product samples as per inquiry and current availability. Payment terms are flexible, tailored to customer needs, and include both advance and milestone payments for smooth transaction processing. Goods transport is handled through trusted logistics partners, ensuring secure delivery of your order. Expenditure for shipping and sample provision can be discussed at the time of order. Standard delivery time depends on quantity and customization, with prompt dispatch upon completion of manufacturing processes.

FAQ's of SS Sight Glass Valve:

Q: How is the SS Sight Glass Valve installed in a process system?

A: Installation is straightforward and can be done in either horizontal or vertical pipeline orientations. Select from flanged, threaded, or welded end connections to suit your system, and refer to the provided manual for guidance.

Q: What are the primary advantages of using borosilicate toughened glass in this valve?

A: Borosilicate toughened glass offers exceptional thermal resistance and mechanical strength, providing a clear, unobstructed view of your process media while withstanding high pressure and temperature variations.

Q: When should I choose PTFE, EPDM, or Viton gaskets?

A: Gasket selection depends on your application's chemical compatibility and operational temperature. PTFE is ideal for aggressive chemicals, while EPDM suits food and beverages, and Viton is preferred for high-temperature or solvent-rich environments.

Q: Where is this valve commonly used?

A: Common applications include chemical plants, food and beverage facilities, and pharmaceutical production areas where safe, clear observation of liquid or gas flow is required.

Q: What is the process for cleaning or disassembling the sight glass valve?

A: The valve is engineered for easy disassembly. Simply follow the instructions to remove the glass and seals, allowing for thorough cleaning and maintenance before reassembly.

Q: How does the full view or double window design benefit users?

A: These designs provide maximum visibility, enabling operators to quickly detect changes in flow or contamination for reliable process control and safety.
